TBA Firefly Intubatt
Damper installation system approved with TBA Firefly Intubatt.
System No. Building Element Product Max Size System Detail Approval Reference TBA Firefly Intubatt 1 Masonry, Concrete or Hebel® wall LVH44 450mm x 450mm Intubatt & LVH44 fitted in wall aperture EXOVA EWFA FAS190234 & FAS190235 TBA Firefly Intubatt 2 Masonry, Concrete or Hebel® wall LVH44 450mm x 450mm Intubatt & LVH44 overlapping wall aperture EXOVA EWFA FAS190234 & FAS190235 TBA Firefly Intubatt 3 FR Plasterboard stud wall LVH44 450mm x 450mm Intubatt & LVH44 fitted in wall aperture EXOVA EWFA FAS190234 & FAS190235 TBA Firefly Intubatt 4 FR Plasterboard stud wall LVH44 450mm x 450mm Intubatt & LVH44 overlapping wall aperture EXOVA EWFA FAS190234 & FAS190235 TBA Firefly Intubatt 5 FR Plasterboard stud wall LVH44 450mm x 450mm Intubatt & LVH44 fitted in Intubatt lined aperture EXOVA EWFA FAS190234 & FAS190235 TBA Firefly Intubatt 6 Speedpanel® wall LVH44 450mm x 450mm Intubatt & LVH44 overlapping wall aperture EXOVA EWFA FAS190234 & FAS190235 FRL: -/120/-
Standard Vision: AS1530.4 2005
