Key benefits
Hard wearing and durable seal.
Slim-line, aesthetic design.
Seal screw-fixed.
Suitable for BAL 40, BAL FZ Bushfire sealing requirements.
Standard lengths 2.75m and 3.0m
Gap sizes 10mm/22mm
Fixing method Fixing screws supplied. Fixing holes are pre-drilled and slotted to allow the seals to be adjusted and positioned accurately.
Finishes Silver anodised aluminium with grey cover strip and grey silicone blade.
Approvals Fire: Approved for use on proprietary AS1905.1 fire doors for up to 4 hour fire rating. Smoke: Conforms with BCA Specification C3.4 smoke sealing requirements. Durability: Long term mechanical test, completing 1,000,000 cycles without failure.
This fully mortised aluminium automatic drop seal features a silicone rubber gasket and internal fins. It is used to close the gap under single swing doors to maintain their acoustic, smoke or energy efficiency performance.
LAS8002 si Drop Seal
This face-fixed (or semi-mortised) aluminium automatic drop seal features a silicone rubber gasket and internal fins. It is used to close the gap under single swing doors to maintain their acoustic, smoke or energy efficiency performance.
LAS8003 si Drop Seal
This face fixed (or semi mortised) aluminium automatic drop seal is used to close the gap under single swing doors to maintain their acoustic, smoke or energy efficiency performance.
LAS8006 si Drop Seal
This face-fixed (or semi-mortised) aluminium automatic drop seal features a silicone rubber gasket and internal fins. It is used to close the gap under single swing doors to maintain their acoustic, smoke or energy efficiency performance.
LAS4002 Threshold Plate
Used where the door sill is uneven, this threshold plate creates a level sealing surface that greatly enhances the ability of door bottom seals to restrict the passage of sound, smoke, energy or weather.
LAS3001 si Door Bottom Seal
Door bottom seal ideal for acoustic and smoke containment.
LAS3002 si Door Bottom Seal
Door bottom and meeting stile seals ideal for acoustic and smoke containment.
LAS3003 si Door Bottom Seal
Door bottom seal ideal for acoustic and smoke containment.
LAS3007 si Door Bottom Seal
A weather proof seal which can be fitted without removing the door, and can be used with a choice of threshold plates.
